Edelbrock 1115 1949-53 Fits Ford V8 Flathead Finned Cylinder Head 65cc Set of 2

Edelbrock #1115 Flathead Ford Cylinder Heads – Set of 2 – 65cc – Satin Aluminum

For 1938–53 Ford & Mercury Flathead V8 • Performance Upgrade • Made in USA

🔧 Product Overview

Bring classic performance and style to your Flathead build with the Edelbrock #1115 Cylinder Heads, designed for 1938–1953 Ford and Mercury Flathead V8s. These heads feature the original Edelbrock script logo and are cast in the USA at the Edelbrock Foundry using high-quality T-6 tempered A356 aluminum.

The #1115 heads are internally and externally ribbed for added strength and heat dissipation. They offer a 65cc combustion chamber, allowing an 8.0:1 compression ratio on engines with stock bore and stroke (3/16" base relief). Compression increases approximately 0.3:1 for every 1/8" of stroke increase, making them ideal for mildly to moderately built Flathead motors.

✅ Key Features

• Authentic Edelbrock script logo – classic vintage styling

• Cast from T-6 tempered A356 aluminum for superior strength and performance

• Internally and externally ribbed for added rigidity and heat control

• 65cc combustion chambers support 8.0:1 compression on stock 3/16" relief blocks

• Great cooling efficiency thanks to large water capacity

• Made in the USA at the Edelbrock Foundry

• Satin finish for a period-correct appearance

• Sold as a matched pair (set of 2 heads)

⚙️ Product Specs

🔧 Installation Notes

• Head Gaskets:

  • 1938–48: Use Victor #3036, Fel-Pro #7548, or Edelbrock #7394

  • 1949–53: Use Fel-Pro #1055, Fel-Pro #1056, or Edelbrock #7393

• Recommended Spark Plugs:

  • Champion RC12YC or equivalent, 14mm x ¾" reach with flat gasket seat

• Recommended Stud Kits:

  • 1938–48: Edelbrock #8505

  • 1949–53: Edelbrock #8502

• Generator Stud Kit (1938–48 only): Edelbrock #8506
